12-14
IM 05P02C41-01EN
AlarmStatus
The alarm status can be output to the contact output. (The setpoints below are I relay
numbers.)
► Irelay:UTAdvancedSeriesCommunicationInterface(RS-485,Ethernet)User'sManual
Setpoint
Function
Alarm status
Alarm output
status
4321 4353 Alarm 1
4322 4354 Alarm 2
4323 4355 Alarm 3
4325 4357 Alarm 4
4326 4358 Alarm 5
4327 4359 Alarm 6
4329 4361 Alarm 7
4330 4362 Alarm 8
4337 4369 Loop-2 alarm 1 (in Cascade control)
4338 4370 Loop-2 alarm 2 (in Cascade control)
4339 4371 Loop-2 alarm 3 (in Cascade control)
4341 4373 Loop-2 alarm 4 (in Cascade control)
4342 4374 Loop-2 alarm 5 (in Cascade control)
4343 4375 Loop-2 alarm 6 (in Cascade control)
4345 4377 Loop-2 alarm 7 (in Cascade control)
4346 4378 Loop-2 alarm 8 (in Cascade control)
• Alarm status: The internal alarm status is turned on when an alarm occurs and
turned off in normal condition
• Alarm output status: Contact output status when an alarm occurs (ON in alarm
condition and OFF in normal condition)
However,theoutputstatusdependsonthesettingsofenergized/de-energizedofalarm,
latch action, and contact type.
Theaboveassumesthatthecontacttypeisenergized.(Thencontactisturnedonwhen
an event occurs.)
To output the normal alarm to the contact output, assign the alarm output status.
â–º Alarm action: 11.1 Setting Alarm Type
12.2SettingContactOutputFunction
