12-18
IM 05P02C41-01EN
SystemErrorStatus
Setpoint
Function
Contact status
ON
OFF
4001
System data error
Error occurs
Normal
4002
Calibration value error
4003
User (parameter) default value error
4005
Setup parameter error
4006
Operation parameter error
4017
Corrupted ladder program
4018
Laddercalculationoverow
4019
Ladder program error
4021
Load factor over 100%
4022
Load factor over 200%
4009
Faulty FRAM
12.2SettingContactOutputFunction
348
350
