YOKOGAWA UP55A User Manual

12-17
IM 05P02C41-01EN
Contact Input/Output Functions
12
SystemErrorStatus
Setpoint Function
Contact status
ON OFF
4529 Heater break alarm 1 status Alarm occurs Normal
4530 Heater break alarm 2 status Alarm occurs Normal
4769 Message display interruption 1 status With interruption Without interruption
4770 Message display interruption 2 status With interruption Without interruption
4771 Message display interruption 3 status With interruption Without interruption
4773 Message display interruption 4 status With interruption Without interruption
ErrorStatus
Setpoint Function
Contact status
ON OFF
4065 PV input ADC error
Error occurs Normal
4066
RSP input (E1-terminal area)
ADC error
4067
AIN2 input (E2-terminal area)
ADC error
4069
AIN4 input (E4-terminal area)
ADC error
4073 PV input burnout error
4074
RSP input (E1-terminal area)
burnout error
4075
AIN2 input (E2-terminal area)
burnout error
4077
AIN4 input (E4-terminal area)
burnout error
4070 PV input RJC error
4071 RSP input RJC error
4081
Feedback resistance/current
burnout
4082
Automatic valve position
adjustmenterror
4097 PV input burnout error (Loop 1)
4098 RSP input burnout error (Loop 1)
4101 PV input over-scale (Loop 1)
4102 PV input under-scale (Loop 1)
4111 Auto-tuning time out (Loop 1)
4113 PV input burnout (Loop 2)
4117 PV input over-scale (Loop 2)
4118 PV input under-scale (Loop 2)
4127 Auto-tuning time out (Loop 2)
12.2SettingContactOutputFunction
