YOKOGAWA UP55A User Manual

12-16
IM 05P02C41-01EN
KeyandDisplayStatus
The key and display status can be output to the contact output. (The setpoints below are
I relay numbers.)
Setpoint Function
Contact status
ON OFF
4705 PARAMETER key
Key is pressed Key is not pressed
4706 DISPLAY key
4707 Right arrow key
4708 Down arrow key
4709 SET/ENTER key
4710 Up arrow key
4711 Left key
4716 PTN key
4717 RST key
4718 MODE key
4719 RUN key
OperationModeandStatus
Setpoint Function
Contact status
ON OFF
4177 AUTO/MAN (Loop 1) MAN AUTO
4225 AUTO/MAN (Loop 2) MAN AUTO
4233 LOCAL(LSP)/CASCADE LOCAL CASCADE
4181 Stop of program operation RESET (OFF→ON) –
4182 Start of program operation PROG (OFF→ON) –
4183 Start of local operation LOCAL (OFF→ON) –
4185 Start of remote operation
REMOTE
(OFF→ON)
–
4189 Start of hold operation HOLD (OFF→ON) –
4186 Output tracking status Tracking ON Tracking OFF
4190 Waitag Wait command (ON)
Wait release
command (OFF)
4191 During auto-tuning During AT –
4239 During auto-tuning (Loop 2) During AT –
4265 Pattern end signal (1 s.) Pattern end –
4266 Pattern end signal (3 s.) Pattern end –
4267 Pattern end signal (5 s.) Pattern end –
4257 Wait end signal (1 s.) Wait end –
4258 Wait end signal (3 s.) Wait end –
4259 Wait end signal (5 s.) Wait end –
4261 Controlagforsegmenttransition Wait command (ON)
Wait release
command (OFF)
4209 Duringautomaticvalveadjustment Duringadjustment –
4210
During operartion by the valve position
estimating type
During operation by
estimating type
During operation by
feedback input
4213 Valve is open Open –
4214 Valve is closed Closed –
4256 FAIL output Normal status FAIL status
12.2SettingContactOutputFunction
