Sufxcode(forStandardmodel):Type2≠4
Optionalsufxcode(forDetailedmodel):/Y2
Transistor contact rating: 24 V DC, 50 mA
DO22
DO21
DO23
DO24
DO25
COM
307
308
309
310
311
312
DO
AdditionalContactOutputAccordingtotheSuffixCodes
Sufxcode(forStandardmodel):Type2=3
Optionalsufxcode(forDetailedmodel):/Y1
Transistor contact rating: 24 V DC, 50 mA
DO12
DO11
DO13
DO14
DO15
COM
301
302
303
304
305
306
DO
Sufxcode(forStandardmodel):Type2=3
Optionalsufxcode(forDetailedmodel):/Y3
Transistor contact rating: 24 V DC, 50 mA
DO32
DO31
DO33
DO34
DO35
COM
407
408
409
410
411
412
DO
17.4Wiring
