YOKOGAWA UP55A User Manual

18-23
IM 05P02C41-01EN
Parameters
18
PVInputSettingMenu(Menu:PV)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
SDP
PV input scale
decimal point
position
EASY
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
Depends
on the
input type
SH
Maximum
value of PV
input scale
EASY
-19999to30000,(SL<SH),|SH-SL|≤
30000
Depends
on the
input type
SL
Minimum value
of PV input
scale
EASY
Depends
on the
input type
BSL
PV input
burnout action
STD
OFF: Disable
UP: Upscale
DOWN: Downscale
Depends
on the
input type
RJC
PV input
reference
junction
compensation
PRO
OFF: RJC OFF
ON: RJC ON
ON
ERJC
PV input
external RJC
setpoint
PRO -10.0 to 60.0 (°C) 0.0
A.BS
PV analog
input bias
STD
-100.0 to 100.0% of PV input range span
(EUS)
0.0 % of
PV input
range
span
A.FL
PV analog
inputlter
STD OFF, 1 to 120 s OFF
A.SR
PV analog
input square
root extraction
PRO
OFF: No square root extraction.
1: Compute the square root. (The slope
equals “1.”)
2: Compute the square root. (The slope
equals “0.”)
OFF
A.LC
PV analog
input low signal
cutoff
PRO 0.0 to 5.0% 1.0%
18.2ListofParameters
