18-24
IM 05P02C41-01EN
RSPSettingMenu(Menu:RSP)(E1terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
IN
RSP remote input
type
EASY
0.4-2V: 0.400 to 2.000 V
1-5V: 1.000 to 5.000 V
0-2V: 0.000 to 2.000 V
0-10V: 0.00 to 10.00 V
0-125: 0.000 to 1.250 V
For option /DR, RSP remote input
type is same as PV input type.
1-5V
UNIT
RSP remote input
unit
EASY
-: No unit
C: Degree Celsius
-: No unit
--: No unit
---: No unit
F: Degree Fahrenheit
C
RH
Maximum value of
RSP remote input
range
EASY
Depends on the input type.
- For temperature input (with /DR
option) -
Set the temperature range that
is actually controlled. (RL<RH)
- For voltage / current (with /DR
option) input -
Set the range of a voltage /
current signal that is applied.
The scale across which the
voltage / current signal is
actually controlled should be
set using the maximum value of
input scale (SH) and minimum
value of input scale (SL).
(Input is always 0% when RL =
RH.)
Depends on
the input type
RL
Minimum value of
RSP remote input
range
EASY
Depends on
the input type
SDP
RSP remote input
scale decimal point
position
EASY
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
Depends on
the input type
SH
Maximum value of
RSP remote input
scale
EASY
-19999 to 30000, (SL<SH), | SH -
SL|≤30000
Depends on
the input type
SL
Minimum value of
RSP remote input
scale
EASY
Depends on
the input type
BSL
RSP remote input
burnout action
STD
OFF: Disable
UP: Upscale
DOWN: Downscale
Depends on
the input type
RJC
RSP remote input
referencejunction
compensation (for
/DR option)
PRO
OFF: RJC OFF
ON: RJC ON
ON
ERJC
RSP remote input
external RJC
setpoint (for /DR
option)
PRO -10.0 to 60.0 (°C) 0.0
RTD.S RTD wiring system STD
3-W: 3-wire system
4-W: 4-wire system
3-W
When each parameter is displayed, the terminal area (E1) is displayed on Group display.
18.2ListofParameters
