YOKOGAWA UP55A User Manual

18-25
IM 05P02C41-01EN
Parameters
18
RSPInputSettingMenu(Menu:RSP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
A.BS
RSP aux. analog
input bias
PRO
-100.0 to 100.0% of RSP input
range span (EUS)
0.0 % of RSP
input range
span
A.FL
RSP aux. analog
inputlter
PRO OFF, 1 to 120 s OFF
A.SR
RSP aux. analog
input square root
extraction
PRO
OFF: No square root extraction.
1: Compute the square root. (The
slope equals “1.”)
2: Compute the square root. (The
slope equals “0.”)
OFF
A.LC
RSP aux. analog
input low signal
cutoff
PRO 0.0 to 5.0% 1.0%
DI6.D DI16 contact type PRO
0: The assigned function is enabled
when the contact is closed.
1: The assigned function is enabled
when the contact is opened.
0
When each parameter is displayed, the terminal area (E1) is displayed on Group display.
18.2ListofParameters
