YOKOGAWA UP55A User Manual

5-5
IM 05P02C41-01EN
Quick Setting Function
5
5.1SettingUsingQuickSettingFunction
Input Function (Continued)
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
SDP
PV input scale
decimal point
position
EASY
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
4: Four decimal places
PV
SH
Maximum value of
PV input scale
EASY
-19999 to 30000, (SL<SH),
|SH-SL|≤30000
SL
Minimum value of
PV input scale
EASY
► Inputsetting:7.1SettingFunctionsofPVInput,RemoteInput,andAuxiliaryAnalogInput
OutputFunction
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
OT
Output type selection EASY
Control output or Heating-side
control output (Lower two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
04: OUT2 terminals (voltage pulse)
05: OUT2 terminals (current)
06: OUT2 terminals (relay/triac)
Cooling-side control output (Upper
two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
04: OUT2 terminals (voltage pulse)
05: OUT2 terminals (current)
06: OUT2 terminals (relay/triac)
OUT
CT
Control output cycle
time
Heating-side control
output cycle time
(in Heating/cooling
control)
EASY
0.5 to 1000.0 s
CTc
Cooling-side control
output cycle time
EASY
► Outputtype:10.1SettingControlOutputType
► Cycletime:10.2SettingControlOutputCycleTime
