Port Trunk Example 161
2
Prepare ports 1, 3, 5 and 7 on the lower Switch for port trunking:
a
Use the web interface to ensure that the ports have an identical
configuration:
b
Use the Port Trunk Setup page of the web interface to specify that
ports 1, 3, 5 and 7 are ports of the port trunk.
3
Connect port 13 on the higher Switch to port 1 on the lower Switch.
4
Connect port 15 on the higher Switch to port 3 on the lower Switch.
5
Connect port 17 on the higher Switch to port 5 on the lower Switch.
6
Connect port 19 on the higher Switch to port 7 on the lower Switch.
