10. Take a second exposure setting the following parameters: 86 kV, 12 mA, 3 s and
verify that the measured values are in the acceptance limits listed in the
following table.
Parameter
Acceptance range
kV
mA
t (s)
kV feedback (± 8%)
mA feedback (± 10 %)
Time (± 5 %)
60
2
3
2.76 to 3.24 V
0.9 to 1.1 V
2.85 to 3.15 s
86
12
3
3.96 to 4.64 V
3.6 to 4.4 V
2.85 to 3.15 s
11. In case the test fails (results do not match the indicated values), perform the
following actions according to which parameter is out of the acceptance range:
• kV out of range: follow the instructions described at paragraph 9.2.7.2
• mA out of range: follow the instructions described at paragraph 9.2.7.4
• time out of range: replace the generator board.
