SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
3
8.3 Logs 146
8.4 Machine configuration and setup 147
9. TROUBLESHOOTING 153
9.1 LEDs 153
9.1.1 MCU board A1 LEDs 153
9.1.2 Generator board A2 LEDs 154
9.1.3 3D Power Sensor board A10 LEDs 155
9.1.4 CCU Ceph Control Board A11 LEDs 155
9.1.5 Collimator Driver Board A12 LED 156
9.1.6 Ceph Driver Board A13 LEDs 157
9.1.7 Ceph sensor power supply board A14 LED 157
9.2 Displayed messages 158
9.2.1 Errors with code from E001 to E003 162
9.2.2 Errors with code from E100 to E104 162
9.2.3 Errors with code from E200 to E299 164
9.2.4 Errors with code from E300 to E399 170
9.2.5 Error with code from E500 to E505 173
9.2.6 Error with code from E600 to E680 174
9.2.7 Error with code from 750 to 770 184
9.2.8 Errors with code E850 and E852 193
9.2.9 Error with code from E1201 to E1205 195
9.2.10 Error with code from 1401 to 1405 195
9.3 User Interface (G.U.I.) messages 204
9.3.1 “Unit and computer not synchronized” 204
9.3.2 “Sensor not ready” 204
9.3.3 “Software error” 204
9.4 System Anomalies 205
9.4.1 White panoramic image or/and empty volumes 205
9.4.2 3D Bad reconstruction 206
9.4.3 Panoramic acquisition with less frames 207
9.4.4 Asymmetries on the panoramic images 207
9.4.5 Unit/MCU connection problems 208
9.4.6 The column does not moves 209
10. PERIODIC MAINTENANCE 210
10.1 Service tools 212
10.2 Sensor Calibration 213
10.2.1 Password generation 223
11. CORRECTIVE MAINTENANCE 226
11.1 Firmware upgrade 226
