Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-91
SCPI Commands
:PAGE:CHANnels[:CDEFinition]:SMU<n>:MODE
:PAGE:CHANnels[:CDEFinition]:SMU<n>:MODE
This command sets the output MODE of SMU<n>. This command also has a query
form.
The value <n> is required to specify an SMU number. Valid SMU numbers are
SMU1 through SMU6, depending on the configuration.
At *RST, this value is set to:
Syntax :PAGE:CHANnels [ :CDEFinition] :SMU<n>:MODE V | I | VPULse | IPULse |
COMMon
:PAGE:CHANnels [ :CDEFinition] :SMU<n>:MODE?
Parameter
For the quasi-static CV measurements, V is available for the VAR1 channel, and V
and COMMON are available for the measurement channel.
Query response V | I | VPUL | IPUL | COMM | DIS <newline><^END>
If an SMU is not used, the response data may be DIS(DISable).
Example OUTPUT @Hp4155;":PAGE:CHAN:SMU1:MODE V"
OUTPUT @Hp4155;":PAGE:CHAN:SMU1:MODE?"
ENTER @Hp4155;A$
SMU OUTPUT MODE
SMU1 COMMon
SMU2 I
SMU3 and SMU4 V
SMU5 and SMU6 Not defined.
Parameter Type Explanation
V character Voltage output mode
I character Current output mode
VPULse character Voltage pulse output mode (sweep mode only)
IPULse character Current pulse output mode (sweep mode only)
COMMon character Common
