5-112 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:DISPlay:ANALysis:LINE(1|2):MODE
:PAGE:DISPlay:ANALysis:LINE(1|2):MODE
This command selects the line mode.
At *RST, this value is NORMal.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):MODE NORMal | GRADient | TANGent |
REGRession | DISable
Parameter
Query response NORM | GRAD | TANG | REGR | DIS <newline><^END>
Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:MODE GRAD"
OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:MODE?"
ENTER @Hp4155;A$
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2)
:AFTer
This command specifies the start position (AFT: var_name, expr) to search for the
point specified by (POS: var_name, expr).
If POINts:MODE is XY (not OPLot), this parameter is ignored.
At *RST, this value is undefined.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):POINt(1 | 2):AFTer var_name, expr
Parameter
Parameter Type Explanation
NORMal character normal mode (use :POINt1 and :POINt2)
GRADient character gradient mode (use :POINt1 and :GRADient)
TANGent character tangent mode (use :TANGent)
REGRession character regression mode (use :POINt1 and :POINt2)
DISable character line is disabled
Parameter Type Explanation
var_name string data variable name
expr string condition expression
