5-170 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:MEASure:MSETup:SMU<n>|:VMU<n> :RANGe
:PAGE:MEASure:MSETup:SMU<n>|:VMU<n>
:RANGe
This command sets the measurement RANGE of SMU<n> or VMU<n>.
<n> is required to specify SMU or VMU number. Valid numbers are SMU1 through
SMU6 (depending on the configuration) and VMU1 through VMU2.
If the RANGe:MODE is AUTO, this parameter is not used.
The specified SMU or VMU must not be DISable.
Syntax :PAGE:MEASure:MSETup:SMU<n> | :VMU<n>:RANGe range | MINimum |
MAXimum
Parameter
Query response range <newline><^END>
range is NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:MSET:SMU1:RANG 2"
OUTPUT @Hp4155;":PAGE:MEAS:MSET:VMU1:RANG MAX"
OUTPUT @Hp4155;":PAGE:MEAS:MSET:SMU1:RANG?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:MEAS:MSET:SMU1:RANG? MAX"
ENTER @Hp4155;A
Parameter Type Explanation
range numeric For voltage measurement using SMU:
2, 20, 40, 100, 200 V
For current measurement using SMU:
10E-12, 100E-12, 1E-9, 10E-9, 100E-9, 1E-6,
10E-6, 100E-6, 1E-3, 10E-3, 100E-3, 1 A
For VMU: 0.2, 2, 20 V
