Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-113
SCPI Commands
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2) :AFTer:STATe
Query response var_name, expr <newline><^END>
var_name and expr are string response data, but do not contain double quote
characters at the beginning and end.
Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:AFT 'DGM','M
AX(DGM)'"
OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:AFT?"
ENTER @Hp4155;A$
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2)
:AFTer:STATe
This command selects whether the start position of search is valid.
If AFTER var_name, expr is set, the STATe is automatically set to ON.
If POINts:MODE is XY (not OPLot), this parameter is ignored.
At *RST, this value is OFF.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):POINt(1 | 2):AFTer:STATe OFF | ON | 0 | 1
Parameter
Query response 0 | 1 <newline><^END>
Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:AFT:STAT ON"
OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:AFT:STAT?"
ENTER @Hp4155;A
Parameter Type Explanation
OFF or 0 boolean search entire area for the point
ON or 1 boolean search for point only after the specified start position
