Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-187
SCPI Commands
:PAGE:MEASure:PGUSetup:PULSe:PGU<n>:WIDTh
:PAGE:MEASure:PGUSetup:PULSe:PGU<n>:WIDTh
This command sets the pulse WIDTH of PGU<n>.
<n> is required to specify PGU number. Valid PGU numbers are PGU1 through
PGU2.
You use this command only if the specified PGU is set to VPULse mode (not V) by
the :PAGE:CHAN:PGU<n>:MODE command.
At *RST, this value is 5 ms.
Syntax :PAGE:MEASure:PGUSetup:PULSe:PGU<n>:WIDTh width | MINimum |
MAXimum
Parameter
Query response width <newline><^END>
width is NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:WIDTH 0.005"
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:WIDTH MIN"
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:WIDTH?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:WIDTH? MIN"
ENTER @Hp4155;A
Parameter Type Explanation
width numeric 1E-6 to 9.99 (s)
