Agilent 4155C/4156C SCPI Command Reference, Edition 1 3-11
Status Reporting Structure
Operation Status Register
Table 3-3 Operation Status Register
Bit Definition Explanation
0 Calibrating 4155C/4156C is currently performing a
calibration.
1 to 2 NOT USED Always zero.
3 Sweeping A sweep is in progress.
4 Measuring 4155C/4156C is actively measuring (sweep
or sampling measurement).
5 Waiting for Trigger 4155C/4156C is currently waiting for a
trigger input.
6 to 7 NOT USED Always zero.
8 Standby 4155C/4156C is currently in the standby
state.
9 Stressing 4155C/4156C is currently in the stress forcing
state.
10 to 11 NOT USED Always zero.
12 Printing A print/plot operation is in progress.
13 NOT USED Always zero.
14 Program running A user-defined program is currently in the run
state.
15 NOT USED Always zero.
