Agilent Technologies 8753ET Service Guide

Chapter 2 2-93
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
Figure 2-55 Mismatch Device Verification Setup 2
35.Press .
36.You have completed the system verification procedure when the analyzer displays
Ver Def 4 DONE.
In Case of Difficulty
1. Inspect all connections.
CAUTION Do not disconnect the cables from the analyzer test ports. Doing so will
invalidate the calibration that you have done earlier.
2. Press . Using the front panel knob, highlight the title of the
enhanced response calibration that you did earlier, then press .
3. Repeat the “Device Verification” procedure.
4. If the analyzer still fails the test, check the measurement calibration as follows:
a. Press .
b. Recall the calibration by pressing
.
c. Use the front panel knob to highlight the calibration you want to recall and press
.
d. Connect the short to reference test port 1.
e. Press .
f. Press .
RETURN
TESTS
31 x1
EXECUTE TEST
CONTINUE
Preset Save/Recall
RECALL STATE
Preset
Save/Recall
SELECT DISK
INTERNAL MEMORY
RETURN
RECALL STATE
Meas
REFLECTION
Sweep Setup
TRIGGER MENU
CONTINUOUS
Scale Ref
SCALE/DIV
0.05 x1
