Agilent Technologies 8753ET Service Guide

Chapter 2 2-53
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Reflection Tracking (Forward) Calibration Coefficient
33.Press .
34.When the analyzer finishes the test, repeat steps 29 through 32.
Load Match (Reverse) Calibration Coefficient
35.Press .
36.When the analyzer finishes the test, repeat steps 22 through 25.
Second Full 2-Port Calibration
37.Connect the equipment as shown in Figure 2-31.
Figure 2-31 Second Full 2-Port Calibration Test Setup
38.Press .
39.Press (or if the
analyzer has Option 075) .
40.Press .
41.Connect the OPEN end of the open/short combination (supplied in the calibration kit) to
reference test port 1.
42.Press .
43.Connect the SHORT end of the open/short combination to reference test port 1.
44.Press .
45.Replace the open/short combination with the termination (supplied in the calibration
kit).
46.Press .
47.Connect the OPEN end of the open/short combination to the analyzer test port 2.
48.Press .
System
SERVICE MENU
TESTS
34 x1
EXECUTE TEST
System
SERVICE MENU
TESTS
42 x1
EXECUTE TEST
Preset Avg
IF BW
3
k/m
Start 300 k/m
Cal
CAL KIT
SELECT CAL KIT
CAL KIT:7mm
CAL KIT: N 75
Ω
RETURN
RETURN
CALIBRATE MENU
FULL 2-PORT
ISOLATION
OMIT ISOLATION
REFLECTION
FORWARD:OPEN
FORWARD:SHORT
FORWARD:LOAD
REVERSE:OPEN
