DeltaChill™ Air Cooled and FreeCool
128
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 67 68 69
Unit Data DCF057DX-13DYV0 DCF057DX-14DYY0 DCF060DX-14DVV0
Nominal Run Amps (1) A 376.9 356.7 405.3
Maximum Start Amps A 644.3 632.3 672.7
Recommended Mains Fuse Size A 400 400 450
Evaporator
Immersion Heater Rating W 170 170 170
Condenser Fan - Per Fan (EC)
Quantity 13 14 14
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 47.9 / 55.2 47.9 / 47.9 55.2 / 55.2
Quantity 3 + 3 3 + 3 3 + 3
Motor Rating kW 29.8 / 33.1 29.8 / 29.8 33.1 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 326 / 326 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 355.0 341.6 376.3
Reactive power reduction/saving (4) kVAr 39.8 28.6 51.0
Maximum Start Amps A 622.4 617.2 643.7
Recommended Mains Fuse Size A 400 400 450
Electronic Soft-start
Nominal Run Amps A 376.9 356.7 405.3
Maximum Start Amps A 513.9 501.9 542.3
Recommended Mains Fuse A 400 400 450
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 355.0 341.6 376.3
Maximum Start Amps A 492.0 486.8 513.3
Recommended Mains Fuse Size A 400 400 450
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 14.8 14.8 21.2
Unit Nominal Run Amps A 391.6 371.2 426.4
Recommended Mains Fuse Size A 450 400 450
Motor Rating kW 8.4 8.4 12.1
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 28.5
Unit Nominal Run Amps A 398.0 377.6 433.7
Recommended Mains Fuse Size A 450 400 450
Motor Rating kW 12.1 12.1 16.4
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 13.9 13.9 19.8
Unit Nominal Run Amps A 388.1 368.0 421.2
Recommended Mains Fuse Size A 450 400 450
Motor Rating kW 8.6 8.6 12.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 26.9
Unit Nominal Run Amps A 393.0 373.0 426.9
Recommended Mains Fuse Size A 450 400 450
Motor Rating kW 12.4 12.4 16.8
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data Extra Quiet
