AIREDALE DeltaChill - Page 129

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
129
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
ELECTRICAL DATA 70 71 72
Unit Data DCF064DX-14FVW0 DCF068DX-14FWW0 DCF069TX-13GPPY
Nominal Run Amps (1) A 417.4 429.6 451.7
Maximum Start Amps A 680.8 665.0 715.1
Recommended Mains Fuse Size A 450 450 500
Evaporator
Immersion Heater Rating W 170 170 250
Condenser Fan - Per Fan (EC)
Quantity 14 14 13
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 59.2 59.2 / 59.2 59.2 / 59.2 / 47.9
Quantity 3 + 3 3 + 3 2 + 2 + 3
Motor Rating kW 33.1 / 36.2 36.2 / 36.2 36.2 / 36.2 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 298 298 / 298 298 / 298 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 389.9 403.6 426.9
Reactive power reduction/saving (4) kVAr 49.0 46.9 45.5
Maximum Start Amps A 653.3 639.0 690.3
Recommended Mains Fuse Size A 450 450 500
Electronic Soft-start
Nominal Run Amps A 417.4 429.6 451.7
Maximum Start Amps A 550.4 545.8 584.7
Recommended Mains Fuse A 450 450 500
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 389.9 403.6 426.9
Maximum Start Amps A 522.9 519.8 559.9
Recommended Mains Fuse Size A 450 450 500
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 21.2
Unit Nominal Run Amps A 438.5 450.6 472.7
Recommended Mains Fuse Size A 500 500 500
Motor Rating kW 12.1 12.1 12.1
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 28.5
Unit Nominal Run Amps A 445.8 457.9 480.0
Recommended Mains Fuse Size A 500 500 500
Motor Rating kW 16.4 16.4 16.4
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 19.8
Unit Nominal Run Amps A 433.4 445.6 467.8
Recommended Mains Fuse Size A 500 500 500
Motor Rating kW 12.4 12.4 12.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 26.9
Unit Nominal Run Amps A 439.1 451.3 473.6
Recommended Mains Fuse Size A 500 500 500
Motor Rating kW 16.8 16.8 16.8
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data Extra Quiet
