AIREDALE DeltaChill - Page 130

Chillers
DeltaChill™ Air Cooled and FreeCool
130
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 73 74 75
Unit Data DCF075TX-14GPYY DCF059DX-15DYV0 DCF061DX-16DVV0
Nominal Run Amps (1) A 481.7 384.7 413.0
Maximum Start Amps A 745.1 652.1 680.4
Recommended Mains Fuse Size A 500 450 450
Evaporator
Immersion Heater Rating W 250 170 170
Condenser Fan - Per Fan (EC)
Quantity 14 15 16
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 47.9 / 47.9 47.9 / 55.2 55.2 / 55.2
Quantity 2 + 3 + 3 3 + 3 3 + 3
Motor Rating kW 36.2 / 29.8 / 29.8 29.8 / 33.1 33.1 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 326 / 326 326 / 326 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 458.0 362.8 384.0
Reactive power reduction/saving (4) kVAr 44.1 39.8 51.1
Maximum Start Amps A 721.4 630.2 651.4
Recommended Mains Fuse Size A 500 450 450
Electronic Soft-start
Nominal Run Amps A 481.7 384.7 413.0
Maximum Start Amps A 614.7 521.7 550.0
Recommended Mains Fuse A 500 450 450
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 458.0 362.8 384.0
Maximum Start Amps A 591.0 499.8 521.0
Recommended Mains Fuse Size A 500 450 450
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 21.2
Unit Nominal Run Amps A 502.6 405.7 434.1
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 12.1 12.1 12.1
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 28.5
Unit Nominal Run Amps A 509.9 413.0 441.4
Recommended Mains Fuse Size A 560 450 500
Motor Rating kW 16.4 16.4 16.4
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 19.8
Unit Nominal Run Amps A 497.9 400.8 428.9
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 12.4 12.4 12.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 26.9
Unit Nominal Run Amps A 503.7 406.5 434.6
Recommended Mains Fuse Size A 560 450 500
Motor Rating kW 16.8 16.8 16.8
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data Extra Quiet
