AIREDALE DeltaChill - Page 145

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
145
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
113
DCC069TR-11GPYY
5 732.1 212.1 694.4 232.5 651.0 255.6 604.2 281.2
6 753.5 213.7 714.3 234.0 669.7 257.1 621.6 282.8
7 775.1 215.4 734.5 235.6 688.6 258.8 639.2 284.5
8 797.0 217.0 754.8 237.2 707.8 260.4 657.2 286.1
9 818.6 218.6 775.4 238.9 727.2 262.1 675.4 287.8
10 840.4 220.2 796.2 240.5 746.8 263.8 693.8 289.6
114
DCC074TR-12GYYY
5 792.7 227.1 751.7 248.6 704.7 273.0 654.1 300.2
6 816.3 228.9 773.5 250.3 725.1 274.7 673.1 301.9
7 840.2 230.7 795.5 252.0 745.8 276.4 692.4 303.6
8 863.7 232.3 817.8 253.7 766.8 278.2 712.0 305.3
9 887.5 234.0 840.4 255.5 788.0 280.0 731.9 307.1
10 911.6 235.8 863.2 257.3 809.5 281.8 752.1 309.0
115
DCC056DR-13DYV0
5 567.7 142.3 541.5 157.2 511.9 174.1 479.0 193.1
6 584.7 143.3 557.8 158.1 527.2 175.0 493.9 194.1
7 601.8 144.3 574.4 159.1 543.1 176.0 508.7 195.0
8 619.2 145.3 591.2 160.1 559.5 177.1 524.4 196.2
9 636.7 146.3 608.2 161.1 575.7 178.1 539.7 197.1
10 654.4 147.4 625.4 162.2 591.7 179.0 555.6 198.2
116
DCC059DR-14DVV0
5 596.1 145.4 568.1 160.8 536.5 178.4 500.9 198.0
6 614.1 146.4 585.5 161.8 553.1 179.3 517.4 199.3
7 632.4 147.4 603.1 162.7 570.0 180.3 533.4 200.3
8 650.9 148.5 621.0 163.8 587.1 181.3 549.1 201.1
9 669.6 149.5 639.1 164.8 604.6 182.4 565.7 202.1
10 688.5 150.6 657.4 165.9 622.2 183.5 582.6 203.2
117
DCC061DR-14DVW0
5 625.2 156.7 596.1 173.2 563.3 192.0 526.6 213.1
6 643.7 157.8 614.0 174.2 580.2 193.0 543.3 214.3
7 662.5 158.9 632.2 175.3 597.7 194.1 559.6 215.3
8 681.5 160.0 650.2 176.3 615.4 195.2 576.4 216.5
9 700.7 161.1 669.2 177.6 633.4 196.4 593.8 217.7
10 720.0 162.3 687.7 178.6 651.5 197.6 611.0 218.8
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
