Alfa Laval S 821 - Fitting the Neck Bearing Cover and Deflector Ring

6.5 ASSEMBLY 6 SERVICE, DISMANTLING, ASSEMBLY
106
13 Fitting the neck bearing cover and deflector ring.
G0868091
a Apply a thin layer of oil and fit the
O-rings and seal rings
o
Deflector ring
c Push the deflector ring
down until it stops.
b Fit the neck bearing cover.
N
O
T
E
The guide pin on the cover should enter one of
the two holes in the bearing housing.
Neck bearing cover
