4.4 SENSORS 4 DESIGN
24
4.4 Sensors
The separator is equipped with a speed
sensor. As options an unbalance sensor and
an interlocking kit can be fitted.
Speed sensor
A speed sensor indicates the speed of the separator. The
correct speed is needed to achieve the best separating
results and for reasons of safety. Refer to type plate for speed
particulars.
Unbalance sensor (optional)
For indication of any abnormal unbalance, the separator can
be equipped with a sensor monitoring the radial position of
the bowl spindle.
Cover interlocking switch (optional)
When the cover is closed the interlocking circuit in the control
system is closed which makes it possible to start the
separator.
G0873471
Unbalance sensor
Speed sensor
Cover interlocking switch
