Alfa Laval S 821 - Paring Tube and Inlet;Outlet Pipe Assembly

117
6 SERVICE, DISMANTLING, ASSEMBLY 6.5 ASSEMBLY
11 Assembling the paring tube and bearing holder .
12 Mounting the paring tube and fitting the inlet and outlet pipe.
i
G0984931
a Apply a thin layer of silicone grease to the
O-ring. Fit the O-ring and bearing
bushing to the paring tube.
i
o
i
o
c Mount the bearing holder with
the flanged bushing into the
paring tube.
b Fit the flanged
bushing
to the bearing
holder.
i
o
Bearing holder
Flanged bushing
Bearing bushing
O-ring
G08622M1
c Apply a thin layer of
silicone grease and fit
the O-rings
to the pipe.
i
o
a Insert the
paring tube
and mount
the axial
support to
the inlet and
outlet pipe.
d Carefully lower the inlet and
outlet pipe assembly into the
top of the distributor.
b Apply a thin layer of silicone grease
and mount the splash sealing
i
