Alfa Laval S 821 - Fitting the Top Disc

6.5 ASSEMBLY 6 SERVICE, DISMANTLING, ASSEMBLY
118
13 Fitting the top disc.
G0862351
a Move the paring tube
to the centre.
The guide rib on the
distributor should enter
one of the two larger
recesses on the top disc.
N
O
T
E
To avoid damaging
the paring tube, turn
it towards the centre
of the pipe.
b Lower the top disc.
