6.3 DISMANTLING 6 SERVICE, DISMANTLING, ASSEMBLY
54
5 Removing the paring tube.
G08630G1
a Remove the top disc from
the inlet and outlet pipe.
N
O
T
E
To avoid damaging the paring
tube, turn it towards the
centre of the pipe.
d Lift up and
remove the paring
tube.
N
O
T
E
If the paring tube sticks; turn the
assembly upside down and use a
drift to carefully tap out the plug.
b Remove the splash sealing.
Bearing holder
Bearing bushing
Flanged bushing
