Alfa Laval S 821 - Spindle Assembly and Component Removal

65
6 SERVICE, DISMANTLING, ASSEMBLY 6.3 DISMANTLING
6 Prepare for removal of spindle assembly.
G0859151
b Remove the screws
N
O
T
E
If the cover sticks, fit two M10
screws to the threaded holes
and tighten.
N
O
T
E
a To facilitate later removal of
plugs, loosen (do not remove)
the plugs on the bearing
housing.
