9.3 Planning of
Installation
9.3.1 Important measurements
Important measurements are:
- minimum lifting height for lifting bowl parts
- shortest distance between driving motor and wall
- space for control and operation
- free passage for dismantling and assembly
- space for maintenance work
- space on floor for machine parts during maintenance
work
For more detailed information, see 8.6.1 Basic size drawing,
page 162 and 8.6.2 Foundation drawing, page 163.
G0873711
