6.5 ASSEMBLY 6 SERVICE, DISMANTLING, ASSEMBLY
96
6.5.2 Driving device
1 Fitting the bottom bearing holder.
G08661B1
a Fit the wing insert, O-rings
and strainer.
d Thread the bottom bearing
holder into the frame and fit
the tool into the bottom
bearing housing.
e Tighten the holder to a torque of 200 Nm.
Too l
Bottom bearing holder
N
O
T
E
Clean the strainer before fitting.
c To secure the bottom
bearing holder into the
frame, apply Loctite
222 on the surfaces
directly above the
upper O-ring.
b Secure the wing insert
with the screw secured
with Loctite 222
Socket
