6.3 DISMANTLING 6 SERVICE, DISMANTLING, ASSEMBLY
58
11 Turn the bowl body upside down.
12 Removing the holder.
G0860821
W
A
R
N
I
N
G
!
Crush hazard
Support the bowl body when turning to prevent it from rolling.
G0860921
b Lift off the holder.
N
O
T
E
If the ring sticks, use two M10
screws in threaded holes to raise
the operating slide holder up and
away from the bowl body.
a Remove and discard the screws and washers.
New screws and washers are included in the
Inspection kit.
