59
6 SERVICE, DISMANTLING, ASSEMBLY 6.3 DISMANTLING
13 Removing the operating slide.
14 Removing the valve plugs from the operating slide.
G0861021
a Lift off the operating slide.
N
O
T
E
If the ring sticks, use two M10 screws in
threaded holes to raise the operating
slide holder up and away from the bowl
body.
G0874881
a Remove the valve plugs using
a drift.
Drift
