57
6 SERVICE, DISMANTLING, ASSEMBLY 6.3 DISMANTLING
9 Removing the cap nut.
10 Removing the bowl body
G0860661
N
O
T
E
Left-hand thread!
a Remove the cap nut
G0860731
a Fit the lifting tool to the bowl body.
b Raise the bowl body off the spindle taper
by turning the lifting eye clock-wise.
c Lift off the bowl body
