6.3 DISMANTLING 6 SERVICE, DISMANTLING, ASSEMBLY
78
7 Removing the coupling from the motor using the optional hydraulic tool.
G08654N1
f Attach the hose from the hand pump to the hydraulic oil inlet.
Ease off the friction coupling by pumping the handle on the
pump until stop.
Release pressure on the hand pump and adjust the nut on the
stud bolt.
Repeat until coupling is loose.
W
A
R
N
I
N
G
!
Crush hazard
The centrifugal clutch is heavy and can fall, causing
injury, when loosened from the motor shaft.
b Fit the holder to the
coupling nave.
d Fit hydraulic cylinder as
shown.
c Fit nut and sleeve to the
stud bolt as shown.
e Fit the plate and fasten with
screws through plate and
holder.
N
O
T
E
First remove the screw, spring washer
and washer according to instructions
a -b, on previous page.
Motor shaft
Sleeve
Holder
Coupling nave
Hydraulic oil inlet
a Fit the sleeve to the
stud bolt.
Fit the stud bolt with
sleeve to the motor
shaft.
