6 SERVICE, DISMANTLING, ASSEMBLY 6.3 DISMANTLING
8 Dismantling of the coupling assembly.
G0865561
a Remove the snap rings.
b Drive out the coupling hub.
c Turn the coupling the other way round and
drive out the ball bearings using the
mounting tool.
Support
Wooden support
N
O
T
E
Always discard used bearings.
