6.3 DISMANTLING 6 SERVICE, DISMANTLING, ASSEMBLY
60
15 Removing the operating water ring.
G0861121
b Lift off the ring.
N
O
T
E
If the ring sticks, use two M8
screws in threaded holes to raise
the operating slide holder up and
away from the bowl body.
a Remove and discard the screws.
New screws are included in the Inspection kit.
