6.5 ASSEMBLY 6 SERVICE, DISMANTLING, ASSEMBLY
112
6 Lifting the bowl body onto the spindle taper.
G0861731
a Put a drop of oil on the spindle taper.
b Wipe off the spindle taper and
nave bore with a dry cloth.
e Carefully lower the bowl body
onto the spindle taper.
d Fit the lifting
tool and lift the
bowl body.
f Remove the lifting tool.
c Turn the bowl body over.
W
A
R
N
I
N
G
!
Crush hazard
Support the bowl body when turning to
prevent it from rolling.
