113
6 SERVICE, DISMANTLING, ASSEMBLY 6.5 ASSEMBLY
7 Fitting and tightening the cap nut.
G0861861
Cap nut
b Apply a thin layer of
molykote grease. Fit and
tighten the cap nut to a
torque of 50 Nm.
N
O
T
E
Left-hand thread!
a To prevent the bowl body from rotating
when fitting the cap nut; Fit one of the
clamps (see page 51) to the bowl body
and one of the screws for the frame
hood in the frame. Fasten a sling
between the clamp and the screw
around the bowl body.
Clamp
Sling
Screw
