85
6 SERVICE, DISMANTLING, ASSEMBLY 6.4 ACTIONS BEFORE ASSEMBLY
6.4.5 Exchange of frame feet
The frame feet have to be changed
occasionally due to rubber deterioration
from age.
When replacing the frame feet, the separator
must be lifted. Follow 6.8.1 Lifting the
separator, page 139.
N
O
T
E
Discard the old frame feet, screws and washers.
G0874421
a Loosen the bolts and prepare to remove
the separator frame
b Lift the separator. See ‘‘Lifting the separator” on
page 139
c Remove the existing frame feet.
d Fit the new feet, screws and washers. Tightening
torque: 160 Nm.
e Place the separator in its original position and
fasten the mounting bolts.
