8.3 CONNECTION LIST 8 TECHNICAL REFERENCE
150
462 Drain of frame top section, lower
701 Motor for separator
Allowed frequency variation:
(momentarily during 5 seconds)
± 5%
± 10%
740 Speed sensor for bowl spindle
• Typ e
• Supply voltage, nominal
• With sensor activated (near metal)
• With sensor not activated (far from metal)
• Number of pulses per revolution
See page 155.
Inductive promixly switch
8 V
Less or equal to 1 mA.
More or equal to 3 mA.
1
752 Position transducer for bearing holder
• Typ e
• Supply voltage
• Operation range (mild steel)
• Output voltage within sensing range
• Load resistance, R
L
See page 156.
Inductive analogue sensor
18 to 30 V DC
0,5 to 2,5 mm
4 to 20 mA
400 Ohm
760 Cover interlocking switch
• Typ e
• Switch rating, resistive load max.
Mechanical limit switch
3 A (at 48 V DC)
1 A (at 220 V AC)
