Alfa Laval S 821 - Page 67

67
6 SERVICE, DISMANTLING, ASSEMBLY 6.3 DISMANTLING
8 Place the spindle assembly upside down on a support.
9 Removing the air deflector.
G0859211
Make a support
~120 mm
~185 mm
~6,5 mm
free space
G0859241
Remove the screws and the air
deflector.
