config mac_notification
Purpose Used to configure MAC address notification.
Syntax config mac_notification {interval <int 1-2147483647> | historysize <int 1-500>
Description MAC address notification is used to monitor MAC addresses learned and entered into the FDB.
Parameters interval <int 1-2147483647> – The time in seconds between notifications.The user may choose an interval
between 1 and 2,147,483,647 seconds.
historysize <1-500> – The maximum number of entries listed in the history log used for notification.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the Switch’s MAC address table notification global settings:
AT-9724TS:4# config mac_notification interval 1 historysize
5 0 0
Command: config mac_notification interval 1 historysize 500
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
config mac_notification ports
Purpose Used to configure MAC address notification status settings.
Syntax config mac_notification ports [<portlist> | all] [enable | disable]
Description MAC address notification is used to monitor MAC addresses learned and entered into the FDB.
Parameters <portlist> - Specify a port or range of ports to be configured.The port list is specified by listing the lowest
switch number and the beginning port number on that switch, separated by a colon.Then the highest switch
number, and the highest port number of the range (also separated by a colon) are specified.The beginning and
end of the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4
specifies switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4
– in numerical order. Ports may be listed in only one port aggregation group, that is, link aggregation groups may
not overlap.
all – Entering this command will set all ports on the system.
[enable | disable] – These commands will enable or disable MAC address table notification on the Switch.
Restrictions Only administrator-level users can issue this command.
Example usage:
To enable port 7 for MAC address table notification:
AT-9724TS:4# config mac_notification ports 7 enable
Command: config mac_notification ports 7 enable
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
132
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
