config box_id
Purpose Used to configure box ID. Users can use this command to reassign box Ids.
Syntax config box_id {current_box_id <value 1-12> new_box_id [AUTO | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
9 | 10 | 11 | 12]}
Description This command will assign box IDs to switches in a stack.
Parameters current_box_id – Identifies the Switch being configured. Range is 1-12.
new_box_id – The new ID being assigned to the Switch (box). Range is 1-12.
auto – Allows the box ID to be assigned automatically.
Restrictions Administrator privileges are needed to issue this command.
Example usage:
To change a box ID:
AT-9724TS:4# config box_id current_box_id 1 new_box_id 2
Command: config box_id current_box_id 1 new_box_id 2
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
config box_type
Purpose Used to configure box type.
Syntax config box_type {current_box_id <value 1-12> type [AT-9724TS | BOX_NOTEXIST]}
Description This command will pre-assign the box type of switches in a stack.
Parameters current_box_id – Identifies the Switch being configured. Range is 1-12.
type – Enter the type of switch to be configured.The user may choose between the following:
AT-9724TS – Name of a switch that can be set in the stack.
BOX_NOTEXIST – Identifies a switch which may be added to the stack in future.A box_type may
be assigned to this box, in effect to pre-configure it, as it is added to the stack. If box_type is not
assigned, box is identified as BOX_NOTEXIST and box type will be identified automatically.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure box type:
AT-9724TS:4# config box_type current_box_id 3 type
B O X _ N O T E X I S T
Command: config box_type current_box_id 3 type BOX_NOTEXIST
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
194
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
