config all_boxes_id
Purpose Used to configure box IDs for switches in a stack.
Syntax config all_boxes_id [static_mode | auto_mode]
Description This command will determine the mode of assigning box IDs.
Parameters static_mode– Box IDs assigned by the user.
auto_mode – Box IDs are assigned automatically.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure box type:
AT-9724TS:4# config all_boxes_id auto_mode
Command: config all_boxes_id auto_mode
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
show stack_information
Purpose Used to display the stack information table.
Syntax config all_boxes_id [static_mode | auto_mode]
Description This command displays stack information.
Parameters None.
Restrictions None.
Example usage:
To display stack information:
AT-9724TS:4# show stack_information
Command: show stack_information
B o x U s e r T y p e E x i s t P r i o - P r o m R u n t i m e H / W
I D S e t r i t y v e r s i o n v e r s i o n v e r s i o n
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 A U T O A T - 9 7 2 4 T S e x i s t 1 6 2 . 0 0 - B 0 4 3 . 0 0 - B 1 6 4 A 1
2 - U S R - N O T - C F G n o
3 - U S R - N O T - C F G n o
4 - U S R - N O T - C F G n o
5 - U S R - N O T - C F G n o
6 - U S R - N O T - C F G n o
7 - U S R - N O T - C F G n o
8 - U S R - N O T - C F G n o
1 0 - U S R - N O T - C F G n o
1 1 - U S R - N O T - C F G n o
1 2 - U S R - N O T - C F G n o
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
T o p o l o g y : D U P L E X _ C H A I N
My Box ID : 1
Current state : M A S T E R
Box Count : 1
A T - 9 7 2 4 T S : 4 #
195
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
