Allied Telesis AT-9724TS Reference Manual

C l i p a g i n g : E n a b l e d
MAC Notification : D i s a b l e d
Port Mirror : D i s a b l e d
S N T P : D i s a b l e d
Bootp Relay : D i s a b l e d
DNSR Status : D i s a b l e d
V R R P : D i s a b l e d
HOL Prevention State : E n a b l e d
Syslog Global State : D i s a b l e d
Single IP Management : D i s a b l e d
Dual Image : S u p p o r t e d
A T - 9 7 2 4 T S : 4 #
show switch_mode
Purpose Used to display the current switch mode.
Syntax show switch_mode
Description This command displays the current mode of operation of the switch.
Parameters None.
Restrictions None.
Example usage:
To view the current switch mode:
AT-9724TS:4# show switch_mode
Command:show switch_mode
Switch is in Layer 3 mode
A T - 9 7 2 4 T S : 4 #
show device status
Purpose Used to display the current status of the hardware of the Switch.
Syntax show device_status
Description This command displays the current status of the Switch’s elements.
Parameters None.
Restrictions None.
Example usage:
To view the current hardware status of the Switch:
AT-9724TS:4# show device_status
Command:show device_status
I D Internal Power External Power Side Fan Back Fan
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
2 A c t i v e F a i l O K O K
A T - 9 7 2 4 T S : 4 #
20
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
