Allied Telesis AT-9724TS Reference Manual

Route Source Metric Metric Type
RIP 0 to 16777214 mettype 1
mettype 2
Static 0 to 16777214 mettype 1
mettype 2
Local 0 to 16777214 mettype 1
mettype 2
Allowed Metric Type combinations are mettype 1 or mettype 2.The metric value 0 above will be redistributed in OSPF as the metric 20.
Example usage:
To configure route redistributions:
AT-9724TS:4# config route redistribute dst ospf src all
metric 2
Command: config route redistribute dst ospf src all metric
2
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
config route redistribute dst rip src
Purpose Used configure route redistribution settings for the exchange of RIP routes to OSPF routes on the Switch.
Syntax config route redistribute dst rip src [local | static | ospf | [all | internal | external | type_1 |
type_2 | inter+e1 | inter+e2]] {metric <value>}
Description Route redistribution allows routers on the network that are running different routing protocols to exchange
routing information.This is accomplished by comparing the routes stored in the various router’s routing tables
and assigning appropriate metrics.This information is then exchanged among the various routers according to
the individual routers current routing protocol.The Switch can redistribute routing information between the
OSPF and RIP routing protocols to all routers on the network that are running OSPF or RIP. Routing
information entered into the Static Routing Table on the local switch is also redistributed.
Parameters src {all | internal | external | type_1 | type_2 | inter+e1 | inter+e2} – Allows the selection of the protocol of the
source device.The user may choose between:
all – Specifies both internal an external.
internal – Specifies the internal protocol of the source device.
external – Specifies the external protocol of the source device.
type_1 – Calculates the metric (for RIP to OSPF) by adding the destination’s interface cost to the
metric entered in the Metric field.
type_2 – Uses the metric entered in the Metric field without change.This field applies only when the
destination field is OSPF.
inter+e1 – Specifies the internal protocol AND type 1 of the external protocol.
inter+e2 – Specifies the internal protocol AND type 2 of the external protocol.
metric <value> – Allows the entry of an OSPF interface cost.This is analogous to a Hop Count in the RIP
routing protocol.
Restrictions Only administrator-level users can issue this command.
227
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
