Allied Telesis AT-9724TS Reference Manual

config ospf virtual_link
Purpose Used to configure the OSPF virtual interface settings.
Syntax config ospf virtual_link <area_id> <neighbor_id> {hello_interval <sec 1-65535> |
dead_interval <sec 1-65535> | authentication [none | simple <password 8> | md5 <key_id
1-255>]}
Description This command is used to configure the OSPF virtual interface settings.
Parameters <area_id> – A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely identifies the OSPF
area in the OSPF domain.
<neighbor_id> – The OSPF router ID for the remote area.This is a 32-bit number in the form of an IP address
(xxx.xxx.xxx.xxx) that uniquely identifies the remote area’s Area Border Router.
hello_interval <sec 1-65535> – Allows the specification of the interval between the transmission of OSPF Hello
packets, in seconds. Between 1 and 65535 seconds can be specified.The Hello Interval, Dead Interval,
Authorization Type, and Authorization Key should be the same for all routers on the same network.
dead_interval <sec 1-65535> – Allows the specification of the length of time between the receipt of Hello
packets from a neighbor router before the selected area declares that router down.An interval between 1 and
65535 seconds can be specified.The Dead Interval must be evenly divisible by the Hello Interval.
authentication – Enter the type of authentication preferred.The user may choose between:
none – Choosing this parameter will require no authentication.
simple <password 8> – Choosing this parameter will set a simple authentication which includes a
case-sensitive password of no more than 8 characters.
md5 <key_id 1-255> – Choosing this parameter will set authentication based on md5 encryption.
A previously configured MD5 key ID (1 to 255) is required.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the OSPF virtual interface settings:
AT-9724TS:4# config ospf virtual_link 10.1.1.2
20.1.1.1hello_interval 10
Command: config ospf virtual_link 10.1.1.2 20.1.1.1
hello_interval 10
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
delete ospf virtual_link
Purpose Used to delete an OSPF virtual interface.
Syntax delete ospf virtual_link <area_id> <neighbor_id>
Description This command will delete an OSPF virtual interface from the Switch.
Parameters <area_id> – A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely identifies the OSPF
area in the OSPF domain.
<neighbor_id> – The OSPF router ID for the remote area.This is a 32-bit number in the form of an IP address
(xxx.xxx.xxx.xxx) that uniquely identifies the remote area’s Area Border Router.This is the router ID of the
neighbor router.
Restrictions Only administrator-level users can issue this command.
Example usage:
To delete an OSPF virtual interface from the Switch:
AT-9724TS:4# delete ospf virtual_link 10.1.12 20.1.1.1
Command: delete ospf virtual_link 10.1.12 20.1.1.1
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
266
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
