2 Specification
22 © Copyright Reserved Autonics Co., Ltd.
※1. To change input specification, you must turn OFF the power of KRN100, remove universal
input card, set inner jumper pin (Please refer to 4.2 I/O card.) and re-connect it.
※2. Exception range for better accuracy by sensor (Accuracy after 30min warm-up time)
R,S,C,G: 0≤T≤100 ±4.0℃
B: No regulation accuracy below 400℃
T, U: -200≤T≤-100±3.0℃, -100≤T≤400±2.0℃
◎Room temperature(23℃±5℃)
Cu50Ω: -200≤T≤200±1.0℃, DPt50Ω: -200≤T≤500±1.5℃
◎Out of range of room temperature
Cu50Ω: -200≤T≤200±2.0℃, DPt50Ω: -200≤T≤500±3.0℃
※3. RS485, Ethernet communication output are not available at the same time.
※4. The front USB Device only for data backup and rear USB device is available only for
parameter setting.
※ It is recommended to use shield cable to decrease noise when sensor input cable is longer.
If connecting or disconnecting input/output card when power is ON, it may cause malfunction.
To connect or disconnect input/output card, you must turn OFF the power.
